Small Single Glass Automatic Visual Sorting Machine Price:¥

Online inquiry
Detailed content Specification parameter Product packaging

This machine is suitable for products that can be smoothly placed on glass plates


Automatic material shortage alarm in the fully automatic feeding system


Different products have automatic focusing and variable magnification light source brightness adjustment


Can install 2-4 cameras


Optional packaging machine

Model

RZHX-G500-C4

Detection range (OD)

5-30mm

Equipment size

1400*1100*1850mm (without loading)

Test product materials

No limit (the product does not stick)

Camera Brand

Germany Basler & Daheng

Detection accuracy

±0.01mm

light source

Parallel light + combined light source

Detection speed

1200pcs/min (different products vary according to feeding speed)

Testing platform

Diameter 500mm ultra-transmissive glass detection platform*1pcs

Feeding method

Vibrating disc (customizable)

Software Algorithm

Traditional algorithms + AI deep learning

General parameters

Voltage\Frequency:AC 220-240V\50HZ

Total power: 2.2KW

Air pressure: 0.4-0.6mpa

Noise: <70db

Temperature: -5℃~50℃

Humidity: <70%
